R1 Moto
Product Features
RENAC R1 Moto Series inverter fully meets the market’s demand for high-power single-phase residential models. It is suitable for rural houses and urban villas with larger roof areas. They can substitute to install two or more low power single-phase inverters. While ensuring the revenue of power generation, the system cost can be greatly reduced.
Max. PV
input current
Optional AFCI
protection function
150% PV
input oversizing
Export control function integrated
Over-temperature protection
Type II SPD for both DC and AC
String monitoring and shorter O&M time
Parameter List
| Model | R1-8K | R1-10K |
| Max. PV Input Voltage[V] | 600 | |
| Max. PV Input Current [A] | 32/32 | 32/32 |
| No.of MPPT Trackers/No.of Input Strings per Tracker | 2/2 | 2/2 |
| Max. AC Output Apparent Power [VA] | 8800 | 10000 |
| Max.Efficiency | 98.1% | |
