On Gird Inverter R1 Mini

1.6kW / 2.7kW / 3.3kW | Single Phase, 1 MPPT

RENAC R1 Mini Series inverter is an ideal choice for residential projects with higher power density,wider input voltage range for more flexible installation and a perfect match for high power PV modules.

Model:
R1 Mini


Availability:



Inquire Add to Basket

Product Features

1.6kW / 2.7kW / 3.3kW | Single Phase, 1 MPPT

RENAC R1 Mini Series inverter is an ideal choice for residential projects with higher power density,wider input voltage range for more flexible installation and a perfect match for high power PV modules.

16A

Max. PV

input current
AFCI

Optional AFCI

protection function
150%

150% PV

input oversizing

Export control function integrated
Over-temperature protection
Type II SPD for both DC and AC
Remote firmware upgrade & setting

Parameter List

Model	R1-1K6	R1-2K7	R1-3K3
Max. PV Input Voltage[V]	500	550
Max. PV Input Current [A]	16
No.of MPPT Trackers/No.of Input Strings per Tracker	1/1
Max. AC Output Apparent Power [VA]	1600	2700	3300
Max.Efficiency	97.5%	97.6%	97.6%
